40ft Expandable Modular House
Description
Technical Parameters
Description
1. **Design & Space Efficiency**
- **Compact Transport vs. Expanded Space**: Standard dimensions are 11.8m × 2.2m × 2.48m (L×W×H) when unfolded, expanding to **11.8m × 6.3m × 2.48m** after installation, offering **72–73m²** of usable space .
- **Structural Features**: Include sliding/folding mechanisms with heavy-duty galvanized steel hinges, support pillars (replaceable by walls), and lightweight sandwich panel walls (50–100mm thick) .
2. **Technical Specifications**
- **Materials**:
- Frame: galvanized steel square tubes .
- Walls/Roof: EPS/rock wool/PU sandwich panels (fireproof Grade A) .
- Flooring: 18mm MGO board or bamboo laminate .
- **Performance**:
- Wind resistance: 0.6 kN/m²; seismic resistance: Grade 8 .
- Waterproofing: Withstands 16mm/min rainfall .
- **Customization**: Layouts (1–4 bedrooms), window/door positions, colors, and smart home integration .
3. **Applications**
- **Residential**: Permanent homes, vacation cabins, student housing .
- **Commercial**: Offices, cafes, classrooms, or disaster-relief shelters .
- **Sustainability**: Recycled materials, solar panel compatibility, and reduced construction waste .
Specification
|
Series |
Caravan, Assembled building |
|
Dimension |
Folded : 11.8m(L)*2.2m(w)*2.48m(H); Expanded : 11.8m(L)*6.3m(w)*2.48m(H) ; Internal : 11.8m(L)*6.14m(w)*2.24m(H) |
|
Color |
White or customized (according to MOQ) |
|
Interior |
1 * Bedroom, 1 *bathroom, 1* table space (offce desk or simple kitchen), 1*balcony We can customize size, color, function, etc.according to your requirements |
|
Standard |
US/AU/EU/BSI |
|
Advantage |
Eco-friendly Waterproof Anti-corrosion Wear resistance Fire-resistant: Class A Anti-seismic: 8 degree Typhoon resistance: 12 degree Sound Insulation:40 db Heat Preservation & heat insulation We can customize size, color, function, etc. according to your requirements |
|
Lifespan |
Over 50 years |
|
Scenarios |
Suitable for a variety of scenarios Container hotel, Modern outdoor house, seaside resort, Construction site, Portable Office, Gas station, Gym, Barber shop etc. |
